N-Channel 60 V (D-S) MOSFET DTQ6013N06SG
Din-Tek Semiconductor is proud to announce the launch of our latest power solution: the DTQ6013N06SG SGT MOSFET. Engineered specifically for demanding motor control applications, this power solution delivers unprecedented efficiency and power density in automotive, industrial automation, and robotics systems.
Boasting an ultra-low RDS(on) of just 1.0 mΩ (typ. @ 10V) and a continuous drain current rating of 220A, the DTQ6013N06SG significantly reduces conduction losses while supporting high torque requirements. Its optimized gate charge (Qg = 168 nC typ.) minimizes switching losses in high-frequency PWM motor drives, improving thermal management even at 100% UIS tested ruggedness. Packaged in a space-saving DFN5x6-8L format, it enables compact motor driver PCB designs without compromising its 600A pulsed current capability.
Key advantages include:
Low thermal resistance (RθJC = 1.1°C/W) for sustained operation
Halogen-free/RoHS compliance for eco-sensitive applications
Single avalanche energy (EAS) rated at 506 mJ for reliability in dynamic braking
Ideal for BLDC/stepper motor drivers, battery management systems, and DC-DC converters.
